For cutting of all electrically conductive materials up to 4 0 mm material thickness
•  with water-cooled plasma hand torch PHT-45 W/L (with central connector) and plasma gas air
•  and plasma gouging.
Excellently suitable in crafts, in small and medium-size compa-nies and training centres, for repairs and on construction sites.

Suitable for straight, profile, template and bevel cutting in all positions, for piercing, for hole and slot cutting as well as for plasma gouging.

• Increasing of life time of consumables by direct and effective cooling of plasma torches (Life time of nozzles and cathodes up to 6 times higher!) and no wear of torch bodies
• Soft start circuit at cutting start and piercing increases the life time of nozzles and cathodes additionally.
• Reducing of air consumption by ca. 80 % compared with air-cooled plasma torches

• High labour safety by shock-proof with safety shut-down at cutting with hand torch.
• Control of the plasma gas and the thermal load of the plasma cutting system.

• 2 cutting current steps: 50 and 100 A
• Plasma hand torch with central connector (length 6 m)
• Integrated water cooling for high life-time of consumables with watching by flow indicator
• Oil and water separator as well as justification of plasma gas pressure by reducer/cleaner on rear wall
• Transportation also by crane (4 crane hooks) or fork lift possible.

• Plasma hand torch with central connector (10 m), other lengths on request
• Plasma tractor FE 1 for mechanised cutting of straight cuts (track available) and circles
• Circle attachment with magnetic or suction holder
• Wheel guide (ensures constant distance between torch and work, also for save cutting of contours)
• Bevel cutting attachment for cutting of any bevel for welding seam preparation
• Distance cap for template cutting •  Distance bow and distance cap for constant distance between nozzle and work

Plasma gouging for preparation of welding seams, crack and inclusion removal, cast iron cleaning, surface removal and more, with the plasma cutting system CUTLINE 40W.

The Kjellberg plasma torch PHT-45 W/L with FineFocus-System can be reset from the version for plasma cutting to the application for plasma gouging and vice versa in a few seconds.

There need to be replaced nozzle and protection cap only. With this concept a high availability of the system is guaranteed.

Compared to gouging with carbon electrodes, a host of technological advantages result, i.e.:

• no heat effected zone of the material.
• no grinding.
• lower heat penetration and therefore lower warpage.
• good observation of the process performance.
• noise level and smoke accumulation reduction.

(1) on request 500 V
•  EN 60974-1, VDE 0544, EN 50078, EN 50192, EN 50199, VBG 15 (UVV 26.0).
•  CE sign, manufactured according to DIN EN ISO 9001.
•  S sign, applicable to welding jobs at work places with increased electrical endangerment.
